Keithley 2200 DC Power Supply
TF:
006402-HW-TEK-002
Overview
Keithley 2200 DC Power Supply
| Parameter | Specification |
|---|---|
| Model | Keithley 2200-60-2 |
| Output Voltage | 0 – 60 V |
| Output Current | 0 – 2.5 A |
| Maximum Power | 150 W |
| Voltage Accuracy | ± (0.03% + 6 mV) |
| Current Accuracy | ± (0.05% + 1.5 mA) |
| Setting Resolution | 1 mV / 0.1 mA |
| Readback Resolution | 1 mV / 0.1 mA |
| Load Regulation | < 0.01% + 2 mV / < 0.05% + 0.5 mA |
| Line Regulation | < 0.01% + 2 mV / < 0.05% + 0.05 mA |
| Ripple & Noise (20 Hz–7 MHz) | < 1 mV RMS / < 5 mV p-p / < 3 mA RMS |
| Display Type | Dual-line Vacuum Fluorescent |
| Interfaces | USB, GPIB |
| Remote Sense | Supported |
| Operating Temperature | 0°C – 40°C |
| Power Consumption | 350 VA |
| Input Voltage | 110 V AC (99–132 V RMS) / 220 V AC (198–264 V RMS), 50/60 Hz |
| Dimensions (H × W × D) | 106 × 242 × 384 mm (with boot) |
| Weight | 7 kg |
| Safety Approvals | UL61010-1, EN61010-1, CAN/CSA C22.2 No.61010-1 |
| Included Accessories | 213-CON connector, CS-1638-12 connector, handle, documentation, driver CD |
The Keithley 2200-60-2 is a single-channel programmable DC power supply delivering up to 60 V, 2.5 A, and 150 W output. It provides precise voltage and current control with low noise and high accuracy, making it ideal for research, development, and production testing. Featuring USB and GPIB interfaces, remote sensing, and a dual-line display, it ensures reliable performance in both manual and automated setups.
