Spectra Precision HV1305GC green beam laser
SKU:
006111-HW-SPECTRA-011
Overview
Green means go bigger with the new HV1305GC from Spectra!
| Leveling Accuracy | ± 1.5 mm/30 m, 1/16“ @ 100 ft. 10 arc seconds |
| Operating Diameter w/HL760 | Typ.1200 m (4000 feet) |
| Rotation | Preset 0, 10, 100, 200, 300 and 600 rpm Adjustable in 10 rpm increments >100rpm |
| Scan Angles | Preset 5°, 15°, 45° and 90° Adjustable in 5° increments |
| Laser Type | 510 – 530 nm |
| Laser Class | HV1305GC Class 2 HV1305GC Class 3 |
| Self-leveling Range | Typ. ± 5° (± 8.7%) |
| Leveling Indicators | LED flashes |
| Radio Range (HL760) | up to 100 m (330 ft) |
| Power Source | 10,000 mAh NiMH battery back or 4 x 1.5V D alkaline batteries |
| Battery Life | HV1305C up to 45 hours HV1305GC up to 30 hours |
| Battery Charging Time | < 10 hours |
| Operating Temperature | -20°C to +50°C (-4°F to +122°F) |
| Storage Temperature | -25°C to +70°C (-13°F to +158°F) |
| Tripod Attachments | 5/8 x 11 horizontally and vertically |
| Dust and Waterproof | Yes - IP66 |
| Weight | 3.49 kg (7.7 lbs) |
| Low Voltage Indication | LED battery indicator |
| Product Dimensions | 240mm x 280mm x 180mm |
The automatic self-leveling Spectra Precision® HV1305GC green beam laser is the most rugged, cost-effective lasers that provide both horizontal and vertical alignment. Even in harsh jobsite conditions, the lasers deliver consistently reliable and accurate performance, enabling you to work faster and smarter.
