Salicru SPS 1500 ADV R Line-interactive sine-wave Uninterruptible Power Systems (UPS) 1U rack
-
NG # 00264-HW-SAL-064
Manufactured by:
The Salicru 1500 VA Line-Interactive Sine-Wave Uninterruptible Power Supply (UPS) – 1U Rack is a high-density, space-saving power backup solution designed for IT and telecommunications environments requiring compact integration without compromising performance. Utilizing line-interactive technology with Automatic Voltage Regulation (AVR), it ensures stable voltage levels and delivers a pure sine-wave output, protecting sensitive devices and ensuring continuous, high-quality power.
Specification
TECHNOLOGY Line-interactive FORMAT Rack 1U Rated voltage 230 V Voltage range 100% load 165 ÷ 290V Stabiliser AVR (Buck & Boost) Rated frequency 50 / 60 Hz (auto-detection) Frequency range ±5 Hz Auto~detection of frequency Yes Protection Fuse Rated voltage 230 V Voltage accuracy (battery mode) ±10% Power (VA/W) 1500 / 900 Total harmonic distortion (THDv) <5% linear load / <10% non-linear load Waveform (battery mode) Pure sine wave Frequency 50/60 Hz (same as input) Frequency accuracy (battery mode) ±1 Hz Compatibility with APFC loads Yes (1) Performance Stabiliser mode (AVR) >92% Performance Battery mode >80% Performance in mains mode >95% Admissible overloads in battery mode 110% for 1 min / 130% immediate Admissible overloads in-line mode 110% for 1 min / 130% immediate Socket type IEC C13 No. Of sockets 4 Battery type Pb-Ca sealed, AGM, maintenance-free Charge type I/U (constant current/constant voltage) Recharge time 4 hours to 90% User replaceable battery Yes Battery test Automatic on each start-up + manual Ports RS-232 / DB9 Intelligent slot Slot for SNMP/potential-free contacts/ MODBUS Monitoring software For Windows, Linux and Mac Type LCD + keypad Values Input and output voltage / % load / % battery / backup Levels Connected load / overload / battery / low battery Operating modes Normal / Stabilisation (AVR) / Battery / Fault Alarm Battery / low battery / overload / failure Audible Every 30 s for battery operation. Every 2 s for low battery / Polarity. Every 0,5 s for overcharge. Continuous for fault. Failure Display LCD Cold start (start-up from batteries) Yes Emergency stop (EPO) Yes Operating temperature 0º C ÷ 40º C Relative humidity Up to 95%, non-condensing Maxium operating altitude 2,400 masl Acoustic noise at 1 metre <40 dB Safety EN-IEC 62040-1 Electromagnetic compatibility (EMC) EN 62040-2(C2) Operation EN 62040-3 Corporate certification ISO 9001, ISO 14001, ISO 45001 Depth (mm) 485 Width (mm) 433 Height (mm) 44 Weight (kg) 15.8
Description
With its 1500 VA capacity, this UPS is ideal for network servers, communication systems, rack-mounted IT setups, and small data centers, providing reliable backup during power outages to prevent downtime, data loss, and hardware failures. The 1U rack format offers optimal space utilization in high-density installations where rack space is at a premium.
