Salicru 1000 VA Line-interactive sine-wave Uninterruptible Power Systems (UPS) 1U rack
00263-HW-SAL-063
Overview
The 1000 VA Line-Interactive Sine-Wave Uninterruptible Power Supply (UPS) – 1U Rack is a high-density, space-efficient power protection system designed for IT and communication infrastructures where rack space is limited. Equipped with line-interactive technology and Automatic Voltage Regulation (AVR), it stabilizes voltage fluctuations while delivering a pure sine-wave output, ensuring safe and reliable power for sensitive devices.
| TECHNOLOGY | Line-interactive |
| FORMAT | Rack 1U |
| Rated voltage | 230 V |
| Voltage range 100% load | 165 ÷ 290V |
| Stabiliser | AVR (Buck & Boost) |
| Rated frequency | 50 / 60 Hz (auto-detection) |
| Frequency range | ±5 Hz |
| Auto~detection of frequency | Yes |
| Protection | Fuse |
| Rated voltage | 230 V |
| Voltage accuracy (battery mode) | ±10% |
| Power (VA/W) | 750 / 450 |
| Total harmonic distortion (THDv) | <5% linear load / <10% non-linear load |
| Waveform (battery mode) | Pure sine wave |
| Frequency | 50/60 Hz (same as input) |
| Frequency accuracy (battery mode) | ±1 Hz |
| Compatibility with APFC loads | Yes (1) |
| Performance Stabiliser mode (AVR) | >92% |
| Performance Battery mode | >80% |
| Performance in mains mode | >95% |
| Admissible overloads in battery mode | 110% for 1 min / 130% immediate |
| Admissible overloads in-line mode | 110% for 1 min / 130% immediate |
| Socket type | IEC C13 |
| No. Of sockets | 4 |
| Battery type | Pb-Ca sealed, AGM, maintenance-free |
| Charge type | I/U (constant current/constant voltage) |
| Recharge time | 4 hours to 90% |
| User replaceable battery | Yes |
| Battery test | Automatic on each start-up + manual |
| Ports | RS-232 / DB9 |
| Intelligent slot | Slot for SNMP/potential-free contacts/ MODBUS |
| Monitoring software | For Windows, Linux and Mac |
| Type | LCD + keypad |
| Values | Input and output voltage / % load / % battery / backup |
| Levels | Connected load / overload / battery / low battery |
| Operating modes | Normal / Stabilisation (AVR) / Battery / Fault |
| Alarm | Battery / low battery / overload / failure |
| Audible | Every 30 s for battery operation. Every 2 s for low battery / Polarity. Every 0,5 s for overcharge. Continuous for fault. |
| Failure | Display LCD |
| Cold start (start-up from batteries) | Yes |
| Emergency stop (EPO) | Yes |
| Operating temperature | 0º C ÷ 40º C |
| Relative humidity | Up to 95%, non-condensing |
| Maxium operating altitude | 2,400 masl |
| Acoustic noise at 1 metre | <40 dB |
| Safety | EN-IEC 62040-1 |
| Electromagnetic compatibility (EMC) | EN 62040-2(C2) |
| Operation | EN 62040-3 |
| Corporate certification | ISO 9001, ISO 14001, ISO 45001 |
| Depth (mm) | 216 |
| Width (mm) | 433 |
| Height (mm) | 44 |
| Weight (kg) | 8.4 |
With a 1000 VA capacity, this UPS is ideal for network cabinets, small to medium servers, telecommunication systems, and professional IT setups, providing uninterrupted power during outages to prevent downtime, data loss, or equipment damage. Its 1U rack-mountable format allows seamless integration into high-density environments without compromising valuable rack space.
