Omega Link Long Range Wireless/Modbus IIoT Ethernet Gateways
-
NG # 2244-HW-Omega-015
Manufactured by:
GW-001 Series gateways are designed for long range performance and ease of use. They aggregate data from all connected sensors and transmit it to the Omega Link Cloud where it can be securely accessed from your PC, tablet or phone.
Specification
| Wireless Communication Frequency | Wireless communication is only available on qualifying variants **Maximum range possible when Smart Sensor is powered by USB and without obstruction |
| AC Adapter | DC 12V @ 2A |
| Power over Ethernet | IEEE 802.3at compatible Type 1 Class 3 *PoE only available on Wireless Pro variant |
| RJ45 | 2x ports |
| USB | 2x USB 2.0 |
| DC Jack | DC 12V power input |
| Serial Port | RS232/RS485 |
| Alarm | SSR 36VDC 100mA |
| Antenna | One Antenna for Sub-1G |
| Rating | IP40 |
| Operating Temperature | -20 ℃ to 65 ℃, non-condensing |
| Dimensions | 170 mm L x 100 mm W x 42 mm H (6.69” x 3.93” x 1.65”) |
| Max number of Smart Sensors | Up to 256 Smart Sensors can connect to a wireless gateway unit |
Description
The Omega Link Gateway is easily paired to Omega Link Smart Sensors with the press of a button and will automatically show up on your Omega Link Cloud account. Local data logging for your Smart Sensor devices keeps your data secure in the event of a power or network outage. Reports, History, and E-mail alerts from the Omega Link Cloud keep you informed on the status of all your vital processes.
Omega Link wireless products are designed with state of the art security features to protect your data with robust AES256 encryption and advanced PKA-EC521bit (NIST) elliptic-curve cryptography to protect your data. The gateway features a Trusted Platform Module secure hardware element which protects the safety of all encryption keys and usesX.509 device certificates for secure communication between the gateway and the Omega Link Cloud.
