POC-40 Extreme Compact Embedded Controller
TF:
004982-HW-Neousys-082
Overview
The POC-40 Extreme Compact Embedded Controller is powered by the Intel Elkhart Lake Atom x6211E dual-core processor and is offered in an extremely small form factor.
| Product Available On | Jan 20, 2021 |
|---|---|
| Manufacturer | Neousys |
| Short Description | The POC-40 Extreme Compact Embedded Controller is powered by the Intel Elkhart Lake Atom x6211E dual-core processor and is offered in an extremely small form factor. The POC-40 has a wide operating temperature of -25°C to 70°C due to its fanless cooling system. This embedded controller is designed to operate with most industrial pcs, and complete rugged tasks. This more powerful alternative to a NUC is more flexible and equally affordable. |
| Processor | Intel E;khart Lake Atom x6211E |
| Graphics | Integrated Intel UHD |
| Memory | up to 32GB DDR-4 3200MHz |
| Ethernet Standard | I210 |
| Video Port | 1 DisplayPort |
| Audio | 1x 3.5mm mic in/spkr oout |
| M.2 | Storage M Key SATA 4G/5G B Key WiFi E Key |
| DC Input | 12-20 VDC |
| Power Adapter | 60W recommended |
| Power Input Voltage | 12-20 VDC |
| Power Type | DC |
| Fan | none |
| Weight | 5 lbs estimate |
| Mounting | DIN standard Wall Optional |
| Operating Temperature | -25-70C |
| Storage Temperature | -40-85C |
| Humidity | 10-90% |
| Vibration | Operating, MIL-STD-810G, Method 514.6, Category 4 |
| Shock | Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II |
| EMC | CE/FCC Class A, according to EN 55032 & EN 55024 |
| CPU Cores | 2 |
| CPU Family | Intel Atom |
| Base CPU Speed | Under 2.0 Ghz |
| Video Output | Display Port |
| LAN Ports | 1-4 |
| Serial Ports | 1-2 |
| USB 2.0 | 1-2 |
| USB 3.1 | 1-4 |
| Max Memory | 32 GB |
| Operating System | Windows 10, Linux |
| Effective Memory Speed | 3200 MHz |
| Form Factor | Fanless |
| Native Storage Type | M.2 SATA S80 |
| On/Ignition | Remote On/Off |
The POC-40 has a wide operating temperature of -25°C to 70°C due to its fanless cooling system. This embedded controller is designed to operate with most industrial pcs, and complete rugged tasks. This more powerful alternative to a NUC is more flexible and equally affordable.
