Nuvo-7164GC: Ruggedized GPU Computing Platform Supporting an NVIDIA L4/T4/A2 and Intel 9th/8th-Gen Core Processor
-
NG # 004979-HW-Neousys-079
Manufactured by:
Nuvo-7164GC is a ruggedized AI inference platform designed for advanced inference acceleration applications such as voice, video, image, and recommendation services. It supports an NVIDIA L4/T4/A2 GPU to provide up to 242 TFLOPS in FP16 and 485 TOPs in INT8 for real-time inference based on a trained neural network model. In addition, it supports Intel 9th/8th-Gen Core 6-core/8-core CPU and 64 GB DDR4- 2666, offering a great balance between CPU, GPU, and memory performance.
Specification
Manufacturer Neousys Short Description Nuvo-7164GC is a ruggedized AI inference platform designed for advanced inference acceleration applications such as voice, video, image, and recommendation services. It supports an NVIDIA L4/T4/A2 GPU to provide up to 242 TFLOPS in FP16 and 485 TOPs in INT8 for real-time inference based on a trained neural network model. In addition, it supports Intel 9th/8th-Gen Core 6-core/8-core CPU and 64 GB DDR4- 2666, offering a great balance between CPU, GPU, and memory performance. Processor Supporting Intel 9th/8th-Gen CPU(LGA1151 socket, 65W/35W TDP)
- Intel Core i7-8700/i7-8700T/i7-9700E/i7-9700TE
- Intel Core i5-8500/i5-8500T/i5-9500E/i5-9500TE
- Intel Core i3-8100/i3-8100T/i3-9100E/i3-9100TEGraphics Integrated Intel UHD Graphics 630 Memory Up to 64 GB DDR4 2666/2400 SDRAM (two SODIMM slots) Chipset Intel Q370 platform controller hub AMT Suppors AMT 12.0 Video Port 1x VGA connector, supporting 1920 x 1200 resolution|1x DVI-D connector, supporting 1920 x 1200 resolution|1x DisplayPort connector, supporting 4096 x 2304 resolution Audio 1x 3.5 mm jack for mic-in and speaker-out PCI Express 1x PCIe x16 slot@Gen3, 16-lanes PCIe signal in Cassette for installing NVIDIA® Tesla P4/T4 GPU M.2 1x M.2 2242 B key socket with dual front-accessible SIM sockets, supporting dual SIM mode with selected M.2 LTE module Mini PCI-E 1x full-size mini PCI Express socket with internal SIM socket (mux with mSATA) SATA HDD 2x internal SATA ports for 2.5" HDD/ SSD installation, supporting RAID 0/1 mSATA 1x full-size mSATA port (mux with mini-PCIe) DC Input 1x 3-pin pluggable terminal block for 8VDC~35VDC input Remote Ctrl. & Status Output 1x 3-pin pluggable terminal block for remote control and PWR LED output Dimension 240mm (W) x 225mm (D) x 110.5mm (H) Weight 4.5 Kg (including CPU, GPU, memory and HDD) Mounting Wall-mount mounting bracket or optional DIN-Rail mounting Operating Temperature with 35W CPU and NVIDIA® Tesla P4/ T4|-25°C ~ 60°C|With 65W CPU and NVIDIA® Tesla P4/T4|-25°C ~ 60°C (configured as 35W TDP)|-25°C ~ 50°C (configured as 65W TDP) Storage Temperature -40°C ~ 85°C Humidity 10%~90% , non-condensing Vibration Operating, MIL-STD-810G, Method 514.6, Category 4 Shock Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II EMC CE/FCC Class A, according to EN 55022 & EN 55024 CPU Cores 6, 8 CPU Family Intel Core Base CPU Speed 2.1 to 3.0 GHz Video Output Display Port, DVI-D, VGA LAN Ports 5-8 Serial Ports 3-4 USB 3.1 5-8 Max Memory 64 GB Operating System Windows 10, Linux Effective Memory Speed 2400 MHz, 2666 MHz Form Factor Fanless Native Storage Type 2.5" SSD, mSATA Full, M.2 NVMe SSD On/Ignition Remote On/Off
Description
Nuvo-7164GC is a ruggedized AI inference platform designed for advanced inference acceleration applications such as voice, video, image, and recommendation services. It supports an NVIDIA L4/T4/A2 GPU to provide up to 242 TFLOPS in FP16 and 485 TOPs in INT8 for real-time inference based on a trained neural network model. In addition, it supports Intel 9th/8th-Gen Core 6-core/8-core CPU and 64 GB DDR4- 2666, offering a great balance between CPU, GPU, and memory performance.
Thanks to Neousys' patented Cassette and air tunnel design, which guides the intake air to flow through the passive heat sink of NVIDIA L4/T4/A2, the heat generated by the GPU is effectively dissipated. This promising design guarantees system operation of up to 60°C ambient temperature with sustained 100% GPU loading. What distinguishes Nuvo-7166GC from Nuvo-7164GC is that it has one additional PCIe x16 slot in the Cassette module for a second add-on card installation, making it that much more flexible for specific applications.
