krohne OPTISWITCH 5250 Vibration level switch
-
NG # 006640-HW-KROHNE-040
Manufactured by:
This
seller generally responds in under 48 hours
The OPTISWITCH 5250 is a vibration level switch with a polished probe extension and tuning fork for liquid hygienic applications. It is a universal and reliable device for level detection in vessels. It detects low or high level and is mostly used for overfill, dry-run or pump protection. Installations in pipelines are also possible.
Specification
General information
| Product type | Level switch |
| Product family name | OPTISWITCH |
| Product positioning | With rigid extension for hygienic applications |
| Product variants | OPTISWITCH 5250 C: Compact housing |
| Measurement variables | Level |
| Measurement principle | Vibrating |
| Level measurement type | Point level detection |
| Contact to measured medium | Yes |
| Interface measurement | No |
| Redundancy | No |
| Measured media | Liquids |
| Probe length | 80…6000 mm/ 3…236 in |
| Measuring point | Pressurised tank, Open tank, Open channel, Basin |
Operating conditions
| Process pressure | -1…64 barg/ -14.5…925 psig |
| Process temperature | -50…+250°C/ -58…+482°F |
Materials
| Gaskets | Ethylene propylene diene monomer (EPDM), Fluoroelastomer rubber (FKM/FPM), Kalrez® 6375, PFA |
| Wetted parts | Austenitic stainless steel (1.4404/316L) |
Process connections
| Thread connections | Male: G¾, G1 ¾ NPT, 1 NPT |
| Hygienic connections | Collar ferrule with nut (DIN 11851): DN25, DN40 Tri-Clamp®: 1", 1 ½" Collar ferrule with nut (SMS 1147): 38 mm |
Approvals/Standards
| Certificates/Approvals Others | WHG |
| Certificates/Approvals Ex | ATEX, IECEx, FM, CSA |
| Certificates/Approvals Hygienic | FDA, 3A, EC 1935/2004 |
| Certificates/Approvals Marine | GL, LR |
| Certificates/Approvals Safety | SIL 2 |
| Ingress protection | IP66/67, NEMA4/4X/6 |
Communication
| Discrete outputs | 2-wire (8/16 mA), Contactless, NAMUR, Relay, Transistor |
Description
Vibration level switch with rigid extension for hygienic applications
Point level detection of liquids in the food, beverage and pharmaceutical industry
Probe length: up to 6000 mm / 236"
Density: ≥0.5 g/cm3 / 0.018 lb/in3
-50…+250°C / -58…+482°F; -1…64 barg / -14.5…928 psig
