Hytera XPT Extended Pseudo Trunk System
-
NG # 001446-HW-Hytera-046
Manufactured by:
Specification
System Performance MS Capacity per System 1200 private call / 245 group call BS Specificaition Frequency Range UHF1：400MHz～470MHz; VHF1：136MHz～174MHz; UHF3：350MHz～400MHz; VHF3：210 MHz～270 MHz; UHF5：806 MHz～941 MHz; UHF2：450MHz～527MHz Power Consumption ≤180 W/carrier Dimensions(H×W×D) mm 4-carrier: 600 mm × 600 mm × 1750 mm（37U）; 8-carrier: 600 mm × 600 mm × 1750 mm（37U）; 2-carrier: 600 mm × 600 mm × 675 mm（13U） Weight 8-carrier: ≤ 400 kg; 4-carrier: ≤ 200 kg; 2-carrier: ≤ 110 kg Operating Temperature -30°C～+60°C Storage Temperature -40°C～+85°C Relative Humidity Base Station: 5% to 95%RH; MSO: 10% to 90%RH Working Altitude ≤2000 m Mean Time to Repair(MTTR) 30 minutes Mean Time Between Failures(MTBF) 100,000 hours Receiver RX Sensitivity(Static) -118 dBm@BER≤5% Max. Valid RX Level -10 dBm（BER≤0.01%） Transmitter TX Power Repeater：≤50 W; Antenna connector：≤14 W Adjust Power Range 5 W~50 W
Description
XPT (Extended Pseudo Trunk) is a new distributed trunking system solution developed by Hytera, which is based on Pseudo Trunk technology and combined with advantages of digital trunking system.
