EM-P18R RK3568 Quad-core 18.5 Inch Industrial Panel PC Windows
TF:
006137-HW-EMDOOR-037
| Basic parameters | |
| Dimensions | 457*279*54 mm |
| Machine weight | 3.22kg |
| Machine color | Black |
| Display | 18.5 inch LCD 16:9, resolution 1920*1080 , 250nits |
| Touch screen | 10 PCAP |
| Camera | / |
| I/O Interface | Type A USB: USB3.0*1,USB3.0*1OTG USB2.0 *2 DC IN 12V-24V Power connector *1 3.5mm Standard Earphone Jack *1 RJ45 *1 (10M/100M/i000M adaptive) DB9 PORT RS232*2 (Mainboard switchable to RS485:RS485*1,RS232*1) HDMI*1 |
| Power adapter | AC100V ~ 240Vă50Hz/60Hz output DC 12V/4A |
| Wireless Communications | |
| WIFI | WiFi 802.11a/b/g/n/ac Frequency 2.4G+5.8G dual band WIFI |
| Bluetooth | BT5.0 |
| 2G/3G/4G/5G | 2G/3G/4G |
| GNSS | / |
| Performance parameters | |
| CPU | RK3568 |
| GPU | Mali-G52-2EE |
| Operating system | Android 12 |
| Memory | 4GB |
| Storage capacity | 64GB |
| Battery Performance | |
| Battery | / |
| Data collection | |
| NFC | NO |
| 1D | NO |
| 2D | NO |
| Fingerprint | NO |
| Product reliability | |
| Operating temperature | -20â~60â |
| Storage temperature | -30â~70â |
| Humidity | 95%, no condensation |
| Protection level | IP65 Front Panel |
| Drop height | 1.22m drop resistance |
Emdoor 18.5 inch industrial panel pc P18R integrates the industrial-grade RK3568 ARM chip, delivering powerful performance and energy efficiency for harsh industrial scenarios. Running Android 12, it enables flexible customization and intuitive operation, optimizing productivity across applications.
