EM-P18J Intel Core N5100 18.5 Inch Industrial Panel PC Windows
TF:
006136-HW-EMDOOR-036
| Basic parameters | |
| Dimensions | 457*279*54mm |
| Machine weight | 3.22kg |
| Machine color | Black |
| Display | 18.5 inch LCD 16:9, resolution 1920*1080 , 250nits |
| Touch screen | 10 PCAP |
| Camera | / |
| I/O Interface | Typ eA USB:USB3.0*2 + USB2.0 *2 DC IN 12V-24V Power connector *1 3.5mm Standard Earphone Jack *1 RJ45*2 (10M/100M/1000M adaptive) DB9 PORT RS232*2 (Configurable via onboard jumper cap to: RS485*1, RS232*I) HDMI2.0 Type A*1 |
| Power adapter | AC100V ~ 240V、50Hz/60Hz output DC 12V/4A |
| Wireless Communications | |
| WIFI | WIFI 802.11 (a/b/g/n/ac, frequency: 2.4G+5G dual frequency WIFI |
| Bluetooth | BT5.0 |
| 2G/3G/4G/5G | 2G/3G/4G |
| GNSS | / |
| Performance parameters | |
| CPU | Intel® Celeron® Processor N5100 |
| GPU | Intel UHD |
| Operating system | Windows 11 Pro |
| Memory | 8GB |
| Storage capacity | 128GB |
| Battery Performance | |
| Battery | / |
| Data collection | |
| NFC | NO |
| 1D | NO |
| 2D | NO |
| Fingerprint | NO |
| Product reliability | |
| Operating temperature | -30℃~70℃ |
| Storage temperature | -30℃~70℃ |
| Humidity | 95%, no condensation |
| Protection level | IP65 Front Panel |
| Drop height | 1.22m drop resistance |
Emdoor 18.5 inch Industrial Panel PC Windows P18J is a powerhouse. Inside, it has the new 11th - Gen Intel® Celeron® N5100 processor. This uses the latest Jasper Lake architecture and 10nm process tech. Plus, with 8GB of RAM and 128GB storage, everything runs smoothly, giving you a super responsive experience for your industrial operations.
