EM-IS19N 10.1-inch slim commercial Windows rugged tablet
TF:
006101-HW-EMDOOR-001
| Basic parameters | |
| Dimensions | 10.1",260*174.7*12.7mm |
| Machine weight | About 930g |
| Machine color | Black |
| Display | 10.1",FHD(1200*1920),700 nits |
| Touch screen | 10 point capacitive touch screen,support MPP702 active pen |
| Camera | Front 5.0MP + rear 13.0MP |
| I/O Interface | USB3.2(Type-C) x2 Nano SIM + Micro SD card 12pin POGOPin x1 |
| Power adapter | USB Type-C interface / 33W Adapter (EU) |
| Wireless Communications | |
| WIFI | Intel® Wi-Fi 6 AX101（802.11 ax） |
| Bluetooth | Bluetooth® V5.2 |
| 2G/3G/4G/5G | 4G/5G |
| GNSS | GPS、Glonass |
| Performance parameters | |
| CPU | Intel N150(6MB Cache,up to 3.6GHz,4 cores,4 threads,TDP 6W) |
| GPU | Intel® Graphics |
| Operating system | Windows11 Home |
| Memory | 8GB |
| Storage capacity | 128GB |
| Battery Performance | |
| Battery capacity | 4800mAh/7.4V |
| Type | Battery Li-Ion |
| Battery life | 7.4 hours |
| Data collection | |
| NFC | Front-facing HF-RFID (NFC) reader（NXP300） |
| 1D | YES |
| 2D | NO |
| Fingerprint | YES |
| Product reliability | |
| Operating temperature | -20℃~60℃ |
| Storage temperature | -30℃~70℃ |
| Humidity | 95%, no condensation |
| Protection level | IP67 compliant |
| Drop height | 1.8m drop resistance |
The EM-IS19N is a 10.1" slim (12.7mm), lightweight (930g) rugged tablet with IP67 protection and 1.8m drop resistance. Powered by Intel N150, Intel® Graphics, and Windows 11 Home, it features a 1200x1920 FHD display, Wi-Fi 6, optional 4G/5G, barcode scanner, and NFC. Ideal for logistics and manufacturing, our ODM services deliver tailored B2B three-proof solutions.
