Dräger PointGard 3720
TF:
007014-HW-Dräger-014
Overview
A complete 1-channel gas detection system for continuous monitoring of carbon dioxide in ambient air, equipped with a high-performance plug-and-play electrochemical sensor and housed in a compact, robust IP66-rated enclosure.
| Type | Self-contained gas monitor |
|---|---|
| Measuring Principle | Infrared |
| Cable entry | 1/2" NPT |
| Display | Yes |
| Intrinsic Safety | No |
| Flameproof | No |
| Increased Safety | No |
| SIL | No |
| 4-20 mA | Yes |
| Bus | No |
| HART® | Yes |
| Wireless | No |
Technical Data
| Power Supply | 10-30 V (DC) / 100-240 V (AC) |
|---|---|
| Temperature (operation) | -20°C - 50°C |
| Humidity | 0 to 95% r.h., non-condensing |
| Pressure (hPa) | 700 - 1300 |
| Dimensions (H Ă— W Ă— D) | 25.5x28x12 cm |
| Weight | 3.8 Kg |
| Housing Material | Glass fiber reinforced polyester |
| Degree of protection (IP class) | IP66 |
Approvals
| ATEX | No |
|---|---|
| IECEx | No |
| UL | No |
| CSA | No |
| CE marking | Yes |
| GOST (EAC) | No |
| Performance approval | No |
| Shipping approval (MED) | No |
This integrated gas detection system provides dependable COâ‚‚ monitoring using a proven electrochemical sensor that installs quickly and delivers accurate, stable measurements. Its compact, IP66-protected housing ensures strong resistance to dust, water, and demanding industrial conditions. Designed for easy setup and long-term reliability, it offers a practical solution for facilities requiring continuous carbon dioxide surveillance with minimal maintenance effort.
