Black Box USB-Powered - switch - 8 ports
TF:
2327-HW-BLACK-001
MF:
LBS008A
| General | |
| Approvals | CE, FCC |
| CE Approval | Yes |
| Filtering/Forwarding Rate | 10 Mbps: 14,880 pps; 100 Mbps: 148,800 pps |
| MAC Addresses | LBS005A - 2K LBS008A - 1K |
| Power | From computer's USB port via power cable (included) or 115-VAC, 60-Hz external power supply (included); 4W |
| Standards | IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-T, IEEE802.3x Flow Control |
| Switching Method | Store-and-forward |
| Item Specifications | |
| Connectors | (8) RJ45 |
| Country of Origin | Taiwan |
| Dimensions | 0.8-in. H x 2.4-in. W x 3.1-in. D (2 x 6.2 x 7.9-cm) |
| Indicators | LEDs: Per Unit: (1) Power; Per Port: (1) LINK/ACT |
| Weight | 0.4-lb. (0.182-kg) |
| Physical Specifications | |
| Operating temperature | 0-55°C |
This compact portable Fast Ethernet switch enables easy network expansion and can be powered from a USB port. Autosensing 10-/100-Mbps ports. Autonegotiating half-/full-duplex. Auto-MDI/MDI-X function on all ports so no need for cross-pinned cables. Non-blocking store-and-forward switching method. Easy-to-see LED indicators enable you to view network status. Easy plug-and-play operation. Compact so you can tuck it neatly in the back of your PC.
