Black Box KVXHP-400 - KVM / audio / serial / USB extender - RS-232, USB 2.0, 10 GigE, DisplayPort, 5 GigE
TF:
2363-HW-BLACK-037
MF:
KVXHP-400
| General | |
| CE | Compliant |
| Distance | CAT5e cable: Up to 164 ft. (50 m); CAT6 cable: Up to 328 ft. (100 m); MM Fiber cable: Up to 984 ft. (300 m); SM Fiber cable: Up to 2.48 mi. (4 km) |
| Indicators | (4) Status LEDs (tri-color) |
| MTBF | RX: 516,000 Hours; TX: 533,000 Hours |
| Operating Humidity | 0 to 80%, noncondensing |
| Operating System | OS independent |
| Operating Temperature | 32 to 104° F (0 to 40° C) |
| Power | External 12-VDC, 1.5-Amps |
| Power Consumption | 18 Watts |
| Power Input | 100-240 VAC, 50/60 Hz |
| Power Output | 12 -VDC, 1.5 Amps |
| Resolution | 1920 x 1200 up to 4 HD Monitors. 4K Monitors not fully supported. |
| Resolutions Supported | 4096 x 2160 at 60 Hz |
| RoHS | Compliant |
| Storage Temperature | +14 to +122° F (-10 to +50° C) |
| Weight | RX: 2.96 lbs (1.34 kg);TX: 3 lbs (1.36 kg) |
| Item Specifications | |
| Connectors | TX Input Connectors: (1) MST DisplayPort RX Local Out Connectors: (4) DisplayPort using MST Hub (MST Hub not included) |
| Country of Origin | United Kingdom |
| Dimensions - Receiver | 1.54-in. H x 7.32-in. W x 5.83-in. D (3.9 x 18.6 x 14.8-cm) |
| Dimensions - Transmitter | 1.54-in. H x 7.32-in. W x 5.83-in. D (3.9 x 18.6 x 14.8-cm) |
| Weight - Receiver | 2.73 lb. (1.24 kg) |
| Weight - Transmitter | 2.84 lb. (1.29 kg) |
True Plug and play High-Performance point-to-point KVM extension. Using DisplayPort 1.2 (Multi-Stream Transport) Technology, KVXHP supports up to four external displays transmitted over a single cable. HD video, USB 2.0 (HID), and audio are all transmitted over a single CATx or Fiber cable. Whether your requirements are CATx or fiber, KVXHP is equipped to handle both interfaces providing a single solution for all use cases.
KVXHP supports four external MST enabled DisplayPort monitors with resolutions up to 1920x1200 @ 60Hz using 8 bits per color and 4:4:4 chroma sampling, provides high-quality audio, EDID management, and Emulated USB 2.0.
