ATX-800 V9 T4/T6 UHF Tablet
TF:
003503-HW-AXEM-003
Overview
The ATX-800 V9 rugged tablet with ergonomic design combines advanced data capture modules with a comfortable user experience with the Android 9.0 operating system. With its 8000 mAH battery, it has a long battery life and allows you to use it extensively in the field.
| General specifications | |
| Operating System | Android 9.0; GMS, Android Enterprise, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported |
| CPU | Qualcomm 1.8 GHz Octa-core |
| Extended storage | Supports up to 128 GB Micro SD card |
| Dimensions | 250.8 x 152.0 x 15.0 mm |
| Weight | 700g / 24.7oz (standard version, without UHF option) |
| Display | 8’’ IPS LTPS 1920 x 1200 / IPS LTPS 1280 x 800 |
| Touch panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Battery | Main battery: Li-ion, rechargeable, 8000 mAh (4000 mAh for the ATX-800 T6) Standby: over 500 hours Continuous use: over 10 hours (depending on user environment) Charging time: 5-7 hours (with standard AC adaptor and USB cable) |
| I/O Ports | USB 3.0 Type-C, OTG |
| Keys | 1 front key, 1 volume key, 1 power key |
| Expansion slot | 1 slot for SIM card, 1 slot for SIM / TF card, optional dual PSAM card slots |
| Camera | Rear camera: 13 MP autofocus with flash; front camera: 8 MP |
| Other - general | Sensors: gravity sensor, gyroscope, accelerometer sensor Audio: speaker, microphone |
| Wireless communication | |
| Wifi | Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v,2.4G/5G dual-band, IPV4,IPV6 Fast roaming: PMKID caching, 802.11r, OKC; Operating channels: 2.4G(channel 1~13), 5G(channel 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124, 128,132,136,140,144,49,153,157,161,165),Depends on local regulations Security and encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPI-PSK—EAPTTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc. |
| Bluetooth | Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR |
| 3G / 4G | Europe: 3G: CDMA EVDO: BC0; 4G: TDD-LTE: B38/B39/B40/B41 FDD-LTE: B1/B3/B5/B7/B8/B20, TD-SCDMA: B34/B39, WCDMA: B1/B5/B8; America: 3G: B2/B4/B5, 4G: B2/B4/B5/B7/B12/B13/B17/B28b |
| GPS | GPS/AGPS, GLONASS, BeiDou,Galileo,internal antenna |
| Vo-LTE | Support Vo-LTE HD video voice call |
| User Environnement | |
| Operating temperature | -20°C to 50°C / 4°F to 122°F |
| Storage temperature | -40°C to 70°C / 40°F to 158°F |
| Humidity | 5% RH - 95% RH non condensing |
| Protection grade | IP65 |
| Drop Specification | Multiple 1.5 m / 4.9 ft drops to concrete across the operating temperature range |
| Tumble Specification | 500 x 0.5 m / 1.64 ft falls at room temperature |
| ESD | ±15 KV air discharge, ±8 KV conductive discharge |
| Standard | Compliance with ATA Spec 2000 Chapter 9.5 |
With its intuitive interface and 8″ touch screen, the ATX-800 V9 is easy to use and deploy in any business environment.
The ATX-800 V9 is a reliable and secure device.
ATX-800 V9 T4: base + NFC + UHF long range + 1D/2D
ATX-800 V9 T6: base + NFC + UHF short range + 1D/2D
Test the UHF RFID features of the tablet with the AX'ware application!
