APC Back-UPS Pro, 1500VA/865W, Tower, 120V, 10x NEMA 5-15R outlets, AVR, LCD, User Replaceable Battery
-
NG # 00351-HW-SCHNEIDER-051
Manufactured by:
Protect computers, wireless routers, IOT devices, and security systems with the APC Back-UPS Pro 1500VA. APC Back-UPS Pro provide premium backup battery power during power outages and continuously safeguard devices from fluctuating power conditions and surges. With 10 outlets, this desktop UPS (uninterruptible power supply) provides seamless battery power to connected electronics.
Specification
Run time for load W information_stroke Min-max: 87-865 W 3min 50s Max. Capacity Used information_stroke 100 % Lead time Usually in Stock Main Input Voltage 120 V Main Output Voltage 120 V Kw Rating 865 W Rated power in VA 1500 VA Product or Component Type Uninterruptible power supply (UPS) Input Connection Type NEMA 5-15P output connection type 5 NEMA 5-15R
5 NEMA 5-15R surgeCable length 6 ft (1.8 m) Battery Type Lead-Acid battery Range of Product Back-UPS Pro Run Time Efficiency Included Battery Modules 1 Battery Slots Empty 0 Typical recharge time 8 h RBC Quantity 1 Battery Voltage 24 V Battery Capacity 9.0 Ah Battery Charge Power (Watts) 23 W rated Battery life 3…5 year(s) Replacement battery Battery graph comments This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables including battery age, battery charge level, environmental conditions and characteristics of the connected load. Extendable Run Time 0 Provided equipment User Manual
USB cableNumber of power module free slots 0 Number of power module filled slots 0 Redundant No Height 11.85 in (30.1 cm) Width 4.41 in (11.2 cm) Depth 15.04 in (38.2 cm) Net Weight 26.7 lb(US) (12.1 kg) Mounting preference No preference Mounting Mode Not rack-mountable Two post mountable 0 USB compatible Yes Input Frequency 50/60 Hz +/- 3 Hz auto-sensing Plug standard NEMA
5-15PMax Configurable Power (Watts) 865 W Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz sync to mains Topology Line Interactive Wave type Stepped approximation to a sinewave Maximum configurable power in VA 1500 VA Transfer Time 8ms typical : 12ms maximum Product Certifications NOM
TÜV
ENERGY STAR V2.0 (USA)Equipment protection policy Lifetime : $150000 Ambient air temperature for operation 32…104 °F (0…40 °C) Relative Humidity 0…95 % Operating altitude 0...3000 ft Ambient Air Temperature for Storage 5…113 °F (-15…45 °C) Storage Relative Humidity 0…95 % Storage altitude 0…5000 ft (0.0000000000…1524.0000000000 m) Acoustic level 45 dBA control panel Multi-function LCD status and control console Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Surge energy rating 354 J Filtering Full time multi-pole noise filtering :5% of IEEE surge let-through : zero clamping response time: in Let Through Voltage Rating 300 V Category 11309 - APC RESALE PRODUCTS GTIN 731304268772 Returnability No Country of origin PH Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 15.24 in (38.7 cm) Package 1 Width 19.21 in (48.8 cm) Package 1 Length 9.37 in (23.8 cm) Package 1 Weight 29.43 lb(US) (13.35 kg) SCC14 10731304268779 Warranty 3 years repair or replace
Description
The 900w capacity is ideal for workstations and additional electronics, keeping you connected and productive during power fluctuations. Add up to one external battery pack to increase battery runtime to connected devices when utility power is lost. Model BR24BPG sold separately. Use the three soft-touch buttons on the front to easily configure settings. Included PowerChute software is available to set up automatic graceful shutdown of a connected PC in the event of an extended power outage. Audible alarms provide notification of changing utility power and UPS conditions. Audible alarms can be muted. The LCD display provides details concerning power-load of connected devices, battery runtime based on connected devices, the power level of the battery and more.
