Allen Bradley PanelView 800 Touch Screen HMI - 10 in, TFT LCD Display, 800 x 600pixels
TF:
004005-HW-ALLEN-O05
Overview
Allen Bradley PanelView 800 Touchscreen HMI, 10in Display, TFT LCD Display - 2711R-T10T. When you need a touchscreen input option for your workplace, look to the Allen Bradley PanelView 800 from Rockwell Automation. It has an 800Hz central processing unit (CPU), so it can process input data quickly.
| Product Range | PanelView 800 |
| Display Type | TFT LCD |
| Manufacturer Part No. | 2711R-T10T |
| Display Resolution | 800 x 600pixels |
| Number of Ports | 2 |
| Port Type | Ethernet, USB |
| Processor Speed | 800MHz |
| Onboard Memory | 256 MB |
| Display Size | 10 in |
| Backlighting | Yes |
| IP Rating | IP65 |
| Supply Voltage | 24 V dc |
| Length | 287mm |
| Maximum Operating Temperature | +50°C |
| Width | 225mm |
| Display Colour | Colour |
| Dimensions | 287 x 225 x 55 mm |
| Minimum Operating Temperature | 0°C |
| Interface | Ethernet |
| Depth | 55mm |
A high-resolution 800 x 600 pixel backlit LED (light-emitting diode) display offers a clear and crisp picture. As it supports 65,000 colours, you can be sure detail won't be lost. Depending on your needs, you can use this versatile device in either landscape or portrait mode.
