Allen Bradley 440R / MSR125H/HP Two Hand Control Safety Relay, 24V ac/dc, Dual-Channel, 2 Safety Contacts
TF:
004074-HW-ALLEN-O74
Overview
Rockwell Automation Minotaur 440R MSR125H/HP 2 Channel Safety Relay
Achieve greater control and efficiency with the Minotaur MSR125H/HP Safety Relays by Rockwell Automation. The MSR125H/HP is a logic unit which is designed to monitor and interface two-hand control devices with a safety-related circuit.
| Supply Voltage | 24V ac/dc |
| Number of Channels | 2 |
| Safety Contacts | 2 |
| Function | Two Hand Control |
| Reset Method | Automatic |
| Range | Guardmaster MSR, Minotaur |
| Safety Category ISO 13849-1 | 4 |
| PL ISO 13849-1 | e |
| SIL IEC 61508 | 3 |
| Width | 22.5mm |
| Depth | 114.5mm |
| Series | 440R / MSR125H/HP |
| Length | 99mm |
| Performance Level | e |
These specialty safety relays are suitable for use with mechanical switches and the Bulletin 800Z Zero-Force Touch Buttons. They feature 2 Normally Open safety outputs which have independent and redundant internal contacts to support the safety function. The MSR125HP model has removable terminals, while the MSR125H model has fixed terminals.
